Comparing Aluminum and Copper Compression Sleeves for Wire Rope

Our white paper, Comparison of Aluminum and Copper Compression Sleeve Materials Used for Terminating and Splicing Wire Rope, by C. C. Petersen, MSME, BSET, and P. J. Pisczak, BSME, MEng/Materials, makes the case for choosing copper over aluminum in swaged compression sleeves used to terminate and splice wire rope. Tensile strength alone doesn't tell the whole story. Fracture toughness, energy absorption, and thermal expansion all shape how these sleeves hold up in the field.

How Sleeves Work

Compression sleeves get pressed, or swaged, onto wire rope to form eye splices, cable stops, and terminations. Nicopress sleeves are engineered to deform past their yield point during installation. That plastic deformation work-hardens the metal, so the sleeve keeps the yield and tensile strength of its base material once it's compressed onto the cable.

Tensile Strength Looks Similar on Paper

Ultimate tensile strength (UTS) measures how much stress a material can withstand before it fails. It's determined by pulling a standardized test sample until it breaks. Across published ranges, copper and aluminum alloys show comparable tensile strength values, with copper typically running higher on the low end and roughly matching aluminum at the high end. Taken alone, that data might suggest the two materials perform similarly as sleeve material. They don't.

Fracture Toughness Favors Copper

Fracture toughness (K1C) measures a material's resistance to crack growth, or how much stress a microcrack can withstand before it starts to propagate. Materials with high yield strength but low fracture toughness, like glass, can fail suddenly with little warning. Aluminum and copper alloys overlap in a narrow toughness range, but copper alloys generally sit higher on the scale.

Since swaging a sleeve onto a cable inevitably opens some microcracks while closing others, a tougher material resists that crack propagation better. The copper alloys Nicopress uses fall above the overlap zone with aluminum, giving copper sleeves a real edge in crack resistance.

Copper Absorbs More Energy Before Failure

Beyond peak stress, the area under a material's stress-strain curve represents the energy it absorbs before fracturing, a second way to measure toughness that captures the effects of real-world manufacturing and processing. In Nicopress's own tensile testing, pure copper (Cu 10100) absorbed roughly three times the fracture energy of aluminum (Al 6063), in both annealed and cold-worked states.

For both metals, the annealed samples held about twice the fracture energy of the cold-worked versions. Ductile materials with higher fracture energy, such as copper, outperform more brittle ones even when the brittle material has a higher UTS. That distinction matters directly for wire rope sleeves: The assembly needs to dissipate energy from an overstressed cable, and a sleeve with greater energy-absorbing capacity resists fracture better under load.

Temperature Changes Stress Aluminum More

Every material expands and contracts with temperature at its own rate, as determined by its coefficient of thermal expansion (CTE). Aluminum expands roughly 39% more than copper per degree of temperature change. Cable assemblies rarely experience a constant temperature, so this is essential: Repeated thermal cycling works residual microcracks, stretching and compressing them, which raises crack sensitivity, promotes work hardening and fatigue, and can eventually lead to fracture.

In mixed-material assemblies, such as sleeves on steel cable, aluminum will expand and contract roughly 43% more than the steel it's attached to, versus about 2% for copper. That mismatch between mating parts can loosen or crack the assembly over time, while a copper sleeve tracks much closer to the steel cable's own expansion behavior.

Failure Modes Differ, Not Just Failure Points

Numerous tensile tests show that aluminum and copper fail differently. Aluminum sleeves have shown brittle fracture on eye splices and shear slip, where the swaged aluminum shears away from the sleeve's inner diameter and lets the cable pull free. These failure modes don't necessarily show up in a simple tensile strength comparison, which is why relying on UTS alone as an acceptance criterion can miss real risk.

Choosing a Sleeve Material

Four properties are important for compression sleeve selection:

• Tensile strength
• Fracture toughness
• Fracture energy (work area)
• Thermal expansion

Copper alloys outperform aluminum on the last three, and copper sleeve material typically runs higher in tensile strength in practice, too, even where published ranges overlap. Our white paper recommends weighing all four factors together rather than defaulting to tensile strength as the sole criterion. For critical applications and anywhere human safety is at stake, copper alloys are the stronger choice for compression sleeve materials.

Learn More About the Difference Between Aluminum and Copper Compression Sleeves

For the full paper and complete references, download the PDF of this white paper. Or contact us for assistance in selecting the best material for your application.

Note: This paper doesn't cover every factor that can affect material performance, including pressure, corrosion, fatigue, creep, radiation, and chemical exposure. A full material selection should account for all physical, chemical, and environmental conditions specific to the application.
